Hello, world!

The classic: “Hello, world!”. Or: what does a simple document look like?

The Publisher always works with two files: a data file (data.xml) containing the content and a layout file (layout.xml) with the rules for how that content should appear in the PDF. Both must be valid XML. A good choice for editing them is an XML editor or the free Visual Studio Code editor.

Want to try this right away? Run sp new helloworld to create a directory with both files. Then cd helloworld and sp to generate the PDF.

Hello World example on the command line

The two files

The data file (data.xml) contains the data — here just a short text:

<data>Hello world!</data>

The layout file (layout.xml) describes what should happen with the data:

<Layout
  xmlns="urn:speedata.de:2009/publisher/en"
  xmlns:sd="urn:speedata:2009/publisher/functions/en">

  <Record element="data">
    <PlaceObject>
      <Textblock>
        <Paragraph>
          <Value select="."/>
        </Paragraph>
      </Textblock>
    </PlaceObject>
  </Record>
</Layout>

Generating the PDF

Save both files in an empty directory, open a terminal in that directory and run the Publisher:

$ sp

The $ represents the shell prompt and is not typed. The result is a PDF file publisher.pdf with one page: the text “Hello world!” in the top left corner.

For Windows users: if the Publisher cannot create the PDF, it may be because the same file is still open in another program (Adobe Reader, Windows Explorer).

The example explained

The data file can have any structure as long as it is well-formed XML (see Glossary). In this case there is just one element <data> with the text content Hello world!.

The layout file step by step:

<Layout                                              <!--1-->
  xmlns="urn:speedata.de:2009/publisher/en"
  xmlns:sd="urn:speedata:2009/publisher/functions/en">

  <Record element="data">                            <!--2-->
    <PlaceObject>                                     <!--3-->
      <Textblock>
        <Paragraph>
          <Value select="."/>                         <!--4-->
        </Paragraph>
      </Textblock>
    </PlaceObject>
  </Record>
</Layout>
  1. The root element Layout with two namespaces. The second namespace (sd:) is not needed here yet, but should always be included — it is required for the built-in functions.
  2. Record defines what should happen when the Publisher encounters the element <data> in the data file. Since <data> is the root element, this Record is called automatically at startup.
  3. PlaceObject is the command to output something into the PDF — text, images, tables, boxes, etc.
  4. select="." is an XPath expression: the dot . means “the current data element”. Here the current element is <data>, and its text content is Hello world!. This is exactly the text that appears in the PDF.

What’s next?

The chapter Programming explains in detail how layout and data work together — in particular the interplay of Record and ProcessNode, which allows processing nested data structures.
